Engine Model | 170F/P |
Engine Type | Single cylinder, 4-stroke, forced air-cooled, 25º inclined, camshaft output |
Displacement | 212cc |
Starting Mode | Hand recoil start |
Engine Volume | 0.6L |
Ignition Mode | No contact, transistor T.C.L |
Rated Power | 4.2kw |
Rated Speed | 3600r/min |
Main Clutch type | Automatic centrifugal type |
Ditching Width | 200mm |
Ditching Depth | ≥150mm |
Ditching Speed | >1m/s |
Ditching and Soil Cultivation Device Type | Triangular plowshare type(plowshare type) |
Weeding Width | 500mm |
Net Weight | 64Kg |
Dimensions | 1400*600*1130mm |
Transmission | Belt+Gear |
Connection Mode | Triangle belt |
Vertical Adjustment Range of Handlebar | 60° |
Walking Speed | Fast 9.6km/h,slow 5km/h |
Fuel Consumption Per Unit Operating Area | ≤35kg/hm2 |
Fuel Tank Capacity() | 3.6L |
Soil Raising Speed | >1m/s |
Soil Work Width | 200mm |
Weeding DeviceType | Wing shovel type (weed hoe) |
Handlebar | Adjustable up and down, and operable gear shifting on the handlebar |
Bumper | Black spray plastic, fully protective |
Transmission Box Type | Aluminum alloy die cast transmission |
Support Method | Side feet |
Extinguishing Mode | Knob type flameout switch |
Chain Rail | Width: 150mm |
length:580mm |
Other Specification | Oil bath air filter, ф 20 Flat key shaft output |
Optional Configuration | Color:Orange, Black |
Decal |
Engine:Standard series, X series |
