product details
| 4LZ-1.05C | Model style | Flat crawler | 4LZ-1.05D | Model style | Triangle crawler |
| Size(Length*Width* | 3100*1440*1630 | Size(Length*Width* | 3100*1440*1630 |
| Height) | Height) |
| Weight(KG) | 510 | Weight(KG) | 560 |
| Cutting width(MM) | 1100 | Cutting width(MM) | 1100 |
| Min ground | 190 | Min ground | 190 |
| clearance(MM) | clearance(MM) |
| Average ground | 10.9 | Average ground | 10.9 |
| pressure(KPA) | pressure(KPA) |
| Feeding | 1.05 | Feeding | 1.05 |
| volume(KG/S) | volume(KG/S) |
| Gear shift | 1，2，3，0，-1，-2，-3 | Gear shift | 1,2,3,0,-1,-2,-3 |
| Engine model | KD1100FB DIESEL | Engine model | KD1100FB DIESEL |
| Rated power(KW) | 11 | Rated power(KW) | 11 |
| Power/RPM | 3600 | Power/RPM | 3600 |
| Start method | Electric start | Start method | Electric start |
| Fuel | Diesel | Fuel | Diesel |
