| Product modle | YG6500 | YG8500 | YG10000 | YG12000 | YG12500 | YG13500 |
| Standard model | 5.0KW | 6.0KW | 7.0KW | 8.0KW | 8.5KW | 9.0KW |
| Rated Voltage(V) | 220/380 | 220/380 | 220/380 | 220/380 | 220/380 | 220/380 |
| Rated power(KW) | 5.0 | 6.0 | 7.0 | 8.0 | 8.5 | 9.0 |
| Maximum power(KW) | 5.5 | 7.0 | 7.5 | 8.5 | 9.0 | 9.5 |
| Rated current(A) | 22.5/9 | 27/11 | 31.5/13 | 34.5/14 | 38.5/16 | 40.5/17 |
| Rated frequency(Hz) | 50/60Hz Optional | |||||
| Power Factor | 1/0.8 | |||||
| Number of phase | Single phase/Equal Power-3-Phase,Dual Voltage | |||||
| Fuel tank capacity(L) | 25 | 25 | 25 | 25 | 25 | 25 |
| Continuous Operating Hours (h/75% load): | 6.0-6.5 | 6.0-6.5 | 5.5-6.0 | 5.0-5.5 | 5.0-5.5 | 4.0-4.5 |
| Model of engine | 190F | 190F | 192FA | 192FB | 194F | 196F |
| Engine displacement(cc) | 420 | 420 | 460 | 465 | 500 | 520 |
| Cylinder diameter X stroke(mm) | 90x66 | 90x66 | 92x69 | 92x70 | 94x72 | 96x72 |
| Rated speed(r/min) | 3000/3600 optional | |||||
| Combustion mode | Ignition of contactless transistor | |||||
| Start the way | Manual start/Electric start is optional | |||||
| Cooling way | Forced air cooling | |||||
| Oil capacity(L) | 1.1 | 1.1 | 1.1 | 1.1 | 1.2 | 1.2 |
| Fuel consumption(g/kw.h) | ≤365 | ≤365 | ≤365 | ≤365 | ≤365 | ≤365 |
| Attachment Configuration | Wheels+handrails are optional | |||||
| Net Weight (kg) : | 72 | 74 | 88 | 90 | 92 | 94 |
| Gross weight (kg) : | 75 | 77 | 91 | 93 | 95 | 97 |
| Quantity of containers 40'HQ | 292 | 292 | 292 | 292 | 292 | 292 |
