| Rated frequency | (Hz) | 50 |
| Rated power | (kVA) | 6 |
| Max power | (kVA) | 6.5 |
| Rated voltage | (V) | 230 |
| Rated current | (A) | 26 |
| Rated rotation speed | (rpm) | 3000 |
| Pole No. |
| 2 |
| Phase number |
| Single phase |
| Excitation mode |
| Self-excitation and constant voltage(with AVR) |
| Power factor | (COSΦ) | 1 |
| Insulation grade |
| F |
| Engine model No |
| 192FAE |
| Engine type |
| Single cylinder, in-lined, 4-stroke, air cooled, direct-injected |
| Bore×stroke | (mm) | 92*75 |
| Displacement | (cc) | 499 |
| Compression ratio |
| 19∶1 |
| Rated power | (kW) | 7.6 |
| Lubrication system |
| Pressure splashed |
| Lube oil brand |
| CD Grade Above or SAE 10W-30,SAE15W-40 |
| Lube oil capacity | (L) | 1.65 |
| Starting system |
| 12V Electric system |
| Starting motor capacity | (V-KW) | 12V 1.2KW |
| Charging generator capacity | (V-A) | 12V 3A |
| Battery capacity | (V-Ah) | 12V 36Ah |
| Fuel consumption ratio | (g/kW.h) | 275 |
| Fuel type |
| Diesel: 0＃（summer）-10＃（winter）-35＃（cold） |
| Fuel tank capacity | (L) | 15 |
| Panel type |
| Common panel |
| Output | Receptacle | 2-Single phase |
| Connection pole | Without |
| DC12V output | With |
| Nosie level(7m） | dB(A) | 72 |
